SPECIFICATIONS
Recommended Usage - In-Ceiling Front / Surround Speakers
Type - 2-way coaxial
Woofers - 8 PP (polypropylene) mica cone
Tweeters - 1 fluid-cooled soft dome
Swivel Tweeter and Midrange Driver - (Tweeters)
Paintable Grill with Protective Cover Included - Yes
Frequency Response - 50 Hz 28 kHz
Sensitivity - 90 dB (2.83 V, 1 m)
Input Power (Maximum / Nominal) - 140W / 50W
Impedance - 8 Ohms
Product Dimensions (W x H x D) - 10-3/4" x 4-1/2"
Mounting Depth - 4-1/4
Product Weight (kilograms each) - 1.9
GENERAL SPECIFICATIONS
Speaker Type - 2-way coaxial
Frequency Range - 50 Hz 28 kHz
Nominal Impendance - 8 ohms
I/O Connectors - Push Terminal ( Applicable Cable *Max, Twisted wire: 8mm2/ AWG 8)
METRICS
Diameter (mm) - 283
D (mm) - 120
Weight - 1.9 kgs
