Ten years of ingenuity, with professional technology and attitude brings true lossless enjoymment with the M500 MKII Bluetooth Audio DAC and headphone amplifierfeaturing high performance with audiophile grade materials.
High performance
The M500 features the top performance D/A chip ES9038PRO from ESS Technology. With the high-performance power supply chip ES9311, the noise of ES9311 is as low as 1uVrms. Additionally, the 3rd ES9038PRO circuit design has a surprisingly low distortion of -123dB and is more stable.
Plus, the built-in high-performance headphone amplifier circuit makes it possible to obtain more than 2W output power and less than -120dB distortion when the headphone is placed in a 16 load!
Professional circuit design
The new self-developed CK-02 clock processing circuit greatly reduces clock jitter.
The latesttechnologies
USB uses the latest second-generation XMOS XU-216, a true 23bit USB solution, with customised drivers for the transmission of various high-definition audio, DoP and native DSD can provide better support.
Qualcomm's latest Bluetooth chip supportsLDAC 24bit/96kHz, APTX/HD, SBC, AAC.
USB, optical, coaxial support DSD and MQA decode, coaxial and optical support DOP64 and MQA-CD.
A variety of digital filters for PCM signals
As many as 7 filter modes, allowing you to change the tone suitable for most people's tastes.
Independent volume adjustment function
Headphone and preamp volume are independent of each other and don't interfere with each other.
Built in shield
Built-in shielded, low noise power supply processing, while improving power efficiency and lower power consumption.
Low noise power supply
Specially designed discrete component linear regulated power supply and multiplelow-noise regulated power supplies to provide low noise powerfor analog circuits.
High-quality materials and design
The D300uses a tempered glass display panel for higher light transmission and longer service life, high quality gold-plated input and output jacks, 4 high-end dual op-amps OPA1612 and a lot of audio grade components.
TheM500 MKIIholds Japan Audio Association (JAS) Hi-Res certification.
