Open Box / B-Stock Notes
- exterior grade: 8.0 out of 10 - very good, some surface wear
- item cosmetic note: n/a
- item function: tested
- item exterior packaging: original, packaging may show damage
- note: all open box / b-stock items are final sale
- ALSO note: this item does NOT include UK power adaptors - only comes with US and UK power adapators
LAB POINTS
- audiophile-grade phono preamp
- allows you to plug a turntable directly into a stereo system, amplifier, computer, or any other device that takes line level input
- gold plated RCA inputs and outputs
- high quality metal casing offersshielding from both vibration and electromagnetic interference
- new "green" DC power supply (extremely low idle power usage)
- switch for Moving Magnet (MM) and Moving Coil (MC) cartridges (most cartridges are MM)
- low noise, low distortion
- flat RIAA equalization curve with 60dB of gain (MC), 40 dB gain (MM)
- also available in
KEY FEATURES
- Input Impedence MM: 47k ohms / 120pf
- Input Impedence MC: 100 ohms / 120pF
- Gain MM: 40dB
- Output Voltage MM: 300mV / 1 kHz or 3mV
- Gain MC: 60 dB
- Output Voltage MC: 200 mV / 1 kHz or 0.3 mV
- Noise MM: 86 dB (94 dB - A weighted)
- Noise MC: 68 dB (75 dB - A weighted)
- THD: MM 0.01% / MC 0.05%
- Max. Output: 9.5 V
- RIAA EQ Curve Accuracy: 20 Hz - 20 kHz / max 0.5 dB
- Power Consumption: 18 V / 80 mA DC
- Power Supply: 18 V / 500 mA DC
- Dimensions (WHD): 4.1 x 1.4 x 4.1 in., 103 x 36 x 103 mm
- Weight: 1.3 lbs., 570 g
COMES WITH
- power supply
