LAB POINTS
- next generation portable USB audio MIDI interface
- quick compact connectivity to yourPC, Mac or other device w/ USB-C
- (2) combo XLR / 1/4" instrument/mic inputs for recording w/ individual gain control 48V phantom power switch
- lightweight portable design w/ durable aluminum casing
- monitor inputs, outputs, settings, firmware updatesw/MiniFuse Control Center app
- real-time color coded VU meter for monitoring project volume
- large front-paneloutput level control knob
- monitor mix knob controls balance between input signal and signal from connected computer
- 1/4" headphone output w/ volume knob
- extra USB-A port for charging or powering anadditional device to save on computer socket space
- 5 year manufacturer's warranty
"MiniFuse 2 is a next-gen audio & MIDI interface that gives you everything you need to make music and audio your own way. With unmatched sound quality, smart connectivity, and an exclusive music-making software pack, this is a portable audio companion evolved." - Arturia
TECH SPECS
- inputs: (2) XLR/ 1/4" combo instrument / mic input
- outputs: (2) 1/4" monitor output, 1/4" headphone output
- MIDI: Din In / Out
- Input impedance:16k line /1Minstrument /2.5k mic
- Maximum input level: 22dBu line / 11.5dBu instrument / 9dBu mic
- Gain range: 56dB
- Frequency response 20Hz to 20kHz: /-0.05dB (min gain) line / /-0.06dB (min gain) instrument mic
- Dynamic input range (A-weighted, typical): 110dB
- THD N @ 1kHz (un-weighted, typical): -100dB line mic /-91dB instrument
- Mic PreampEquivalent Input Noise (A-weighted, typical): -129dB
- Output impedance: 94 speakers /10 headphones
- Maximum output level: 12dBuspeakers / 11.4dBu headphones
- Frequency response 20-20kHz: /-0.09dB
- Dynamic output range (A-weighted, typical): 107.5dB speakers /104dB headphones
- THD N @ 1kHz: -101dB typical (un-weighted)
- Headphones Power @ 33ohm: 137mW
- Supported sample rates:44.1kHz, 48kHz, 88.2 kHz,96kHz, 176.4kHz, 192 kHz
- dimensions: 7.9" x 3.9" x 1.65" /200 x 100 x 43mm
- weight: 1.1 lbs. / 0.431 Kg
COMES WITH
- Ableton Live Lite
- Analog Lab Intro
- Arturia FX
- Native Instruments Guitar Rig 6 LE
- Auto-Tune Unlimited
- Splice Creator Plan
